2. Chassis: the whole surface is treated by acid washing and phosphatizing corrosion-resistant cathodic electrophoresis to ensure that it never rusts and corrodes all year round, with excellent smoothness and sturdiness.

3. Floor: non-slip floor

4. Front windshield: acrylic plexiglass; optional folding glass

5. Roof: automotive special PP material injection molding one-piece roof

6. Seat: ergonomic seat, leather fabrics

7. Instrument panel: None

8. Direction system: bidirectional rack and pinion steering system, automatic gap compensation function

9. Lights/Horn: Combination headlights, turn signals, combination rear tail lights, brake lights, electric horn

10. Motor: AC asynchronous motor 3.5KW, superior traction performance, strong overload capacity and long service life.

11.Battery: Superwin lead-acid maintenance-free battery 100AH 5pcs Voltage: 60V

12. Electronic control system: special AC controller, with over-temperature protection circuit, hill assist anti-skidding function, and smoother startup.

13.Charger: Intelligent vehicle charger 60V/15A, charging time <10 hours (discharge rate of 80%)

14. Suspension system: MacPherson independent suspension; coil spring + cylinder hydraulic shock absorption. Integral rear axle, speed ratio 12.31:1 coil spring damping + cylinder hydraulic shock absorption + rear stabilizer bar

15. Brake system: rear wheel hub brake + compound pedal parking

16. Tire form: special ball car tire 205*50-10
